Urethane Wheels for Airports and Logistics
AeroPorter™ DuraGel Wheels
Molded urethane wheels with sealed bearings for baggage carousels, conveyors and parcel sorting systems. Cast in Salinas, California, stocked on the shelf, and running in airport baggage systems today.
- Stocked, ready to ship
- Sealed bearings installed
- 95A and 60D urethane
Stocked on the shelf
Molded ahead and ready to ship. No mold lead time on stock sizes.
Bearings installed
Sealed bearings pressed in and ready to mount. Stainless available.
Built for constant wear
95A and 60D urethane for high load, high cycle duty on carousels and sorters.
New molds on request
No mold for your size? We will make one in our Salinas plant.
Where they run
Carousels, conveyors and sorters wear through wheels. We keep them on the shelf.
Baggage claim carousels, make up units, inbound conveyors, airport distribution centers and parcel sorting systems all turn on small urethane wheels with bearings. They wear on a schedule, and when the OEM part is on a long lead time, the system waits. AeroPorter wheels are cast in Salinas, California and stocked in the sizes baggage and parcel systems use most, so a maintenance team can order a box, not a project.
- Baggage claim carousels and make up units
- Inbound and outbound baggage conveyors
- Airport distribution and cargo centers
- Parcel, postal and logistics sorting systems
Already running in airport baggage systems today, and backed by Green Rubber Kennedy Ag, which supplies belting, bearings and power transmission to airports and logistics operations.
Stock sizes
Molded ahead and shelved. Dimensions are outside diameter by width in inches. Part numbers follow our GPP-WAG system: size, bore, durometer, color.
| Part number | OD × width (in) | Bore | Bearing | Durometer | Color |
|---|---|---|---|---|---|
| GPP-WAG-2060.10-95A-BL | 2.00 × 0.60 | 10 mm | 6201-2RS | 95A | Blue |
| GPP-WAG-2710.20-95A-BL | 2.75 × 1.00 | 20 mm | 6004-2RS | 95A | Blue |
| GPP-WAG-3010.063-95A-OR | 3.00 × 1.00 | 0.630 in | 99502H | 95A | Orange |
| GPP-WAG-3010.17-95A-GN | 3.00 × 1.00 | 17 mm | 6203-2RS | 95A | Green |
| GPP-WAG-3012.050-95A-RD | 3.00 × 1.25 | 0.630 in | 99502H | 95A | Red |
| GPP-WAG-4010.050-95A-GN | 4.00 × 1.00 | 0.500 in | SS6203-2RS-8 | 60D | Green |
| GPP-WAG-4010.063-95A-OR | 4.00 × 1.00 | 0.630 in | 99502H | 95A | Orange |
| GPP-WAG-4010.17-95A-GN | 4.00 × 1.00 | 17 mm | SS6203-2RS | 60D | Green |
| GPP-WAG-4012.063-95A-BN | 4.00 × 1.25 | 0.630 in | 99502H | 95A | Brown |
| GPP-WAG-4207.20-95A-YL | 4.25 × 0.75 | 20 mm | 6304-2RS | 95A | Yellow |
Other sizes, bores, bearings, durometers and colors are made to order. Stainless bearings available on request.
How to order
Not sure which wheel you need? Measure the one you are replacing.
- Outside diameter. Across the face of the wheel, in inches.
- Width. Edge to edge across the tread.
- Bore. The shaft size the bearing rides on, in inches or millimeters.
- How it is used. Carousel, conveyor or sorter, and whether it carries load or guides.
Send those four things and we will match the size and durometer. If we do not have a mold, we will make one.
Quotes and orders
Southern California and airports
Sergio Blanco, Account Manager
A Division of Green Rubber Kennedy Ag
Get a Quote
Send the part number, or the outside diameter, width and bore of the wheel you are replacing, and the quantity. Stock sizes ship from Salinas.
AeroPorter and DuraGel are trademarks of Urethane Specialists, Inc.
